Coaxial Inserts For NMR Sample Tubes

A coaxial insert consists of an upper glass alignment tube with a precise outer diameter that fits very closely within the matching 5mm or 10mm thin wall outer glass NMR tube, ensuring accurate coaxiality and centering of the insert within the outer NMR tube.

The lower glass stem tube, of a smaller diameter, typically holds an external lock or reference material. The smaller diameter stem tube is precision sealed to the upper alignment tube using a highly accurate, state-of-the-art glass working lathe, maintaining the coaxial alignment necessary for the acquisition of high quality spectra.

The accompanying table presents the most commonly used sizes for Bruker and Varian probes. Please note that the last two inserts listed in the table are constructed from quartz glass, whereas the remaining inserts are made from low expansion borosilicate glass (Pyrex® or equivalent ASTM Type 1 Class A glass).

The data in the columns under “Stem Specifications” lists the stem tube outer diameter, length and the volumetric capacity of the stem tube when the entire length is filled (either 50mm or 60mm).

The last column of the table gives the volumetric sample capacity remaining within the outer 5mm or 10mm NMR tube when the coaxial insert is positioned to full depth within the outer tube, as measured to the top of the insert stem tube (again either 50mm or 60mm).

All inserts are made to an overall length of 206mm (8-1/8”), and include a cap for the insert tube along with a special cap to seal the insert to the top of the outer NMR tube.

As always, we would be delighted to quote on custom requests for stem diameters and lengths not given in the accompanying table.

(5mm & 10mm) for external lock & reference solvents. Precision inner cell for use with 5mm & 10mm thin wall NMR tubes. Available for Bruker & Varian spectrometers.

*10mm insert for Bruker & Varian includes our 1008-UP 7” NMR tube

Stem Specifications

Item No.

Tube

Probe

O.D.
(mm)

Length
(mm)

Capacity
(μl)

Sample Capacity

NI5CCI-B

5mm

Bruker

2

50

100

490 μL

View In Legacy Store

NI5CCI-V

5mm

Varian

2

60

120

590 μL

View In Legacy Store

NI10CCI-B*

10mm

Bruker

3

50

215

2.61 mL

View In Legacy Store

NI10CCI-V*

10mm

Varian

3

60

260

3.14 mL

View In Legacy Store

NI5CCI-B-QTZ

5mm

Bruker

3

50

175

285 μL

View In Legacy Store

NI5CCI-V-QTZ

5mm

Varian

3

60

210

340 μL

View In Legacy Store

Item Name

NI5CCI-B Bruker Coaxial Inserts for NMR Tubes, 4mm Tube With 50mm Stem, Includes one S-5-400-7 NMR tube to be used with the Coaxial Insert.

View In Legacy Store

We cannot guarantee the fit of any NMR tube other than the one that is provided with the insert.

Item No.:

NI5CCI-B

Tube:

5mm

Probe:

Bruker

STEM SPECIFICATION
O.D. (mm):

2

STEM SPECIFICATION
Length (mm):

50

STEM SPECIFICATION
Capacity (μl):

100

Sample Capacity:

490 μL

NI5CCI-V Varian Coaxial Inserts for NMR Tubes, 4mm Tube With 60mm Stem, Includes one S-5-400-8 NMR tube to be used with the Coaxial Insert.

View In Legacy Store

We cannot guarantee the fit of any NMR tube other than the one that is provided with the insert.

Item No.:

NI5CCI-V

Tube:

5mm

Probe:

Varian

STEM SPECIFICATION
O.D. (mm):

2

STEM SPECIFICATION
Length (mm):

60

STEM SPECIFICATION
Capacity (μl):

120

Sample Capacity:

590 μL

NI10CCI-B* Bruker Coaxial Inserts for NMR Tubes, 9mm Tube With 50mm Stem, 1/Pack, Includes one 1008-UP-7

View In Legacy Store

We cannot guarantee the fit of any NMR tube other than the one that is provided with the insert.

Item No.:

NI10CCI-B*

Tube:

10mm

Probe:

Bruker

STEM SPECIFICATION
O.D. (mm):

3

STEM SPECIFICATION
Length (mm):

50

STEM SPECIFICATION
Capacity (μl):

215

Sample Capacity:

2.61 mL

NI10CCI-V* Varian Coaxial Inserts for NMR Tubes, 9mm Tube With 60mm Stem, 1/Pack, Includes one 1008-UP-7

View In Legacy Store

We cannot guarantee the fit of any NMR tube other than the one that is provided with the insert.

Item No.:

NI10CCI-V*

Tube:

10mm

Probe:

Varian

STEM SPECIFICATION
O.D. (mm):

3

STEM SPECIFICATION
Length (mm):

60

STEM SPECIFICATION
Capacity (μl):

260

Sample Capacity:

3.14 mL

NI5CCI-B-QTZ Bruker Coaxial Inserts for NMR Tubes, 4mm Quartz Tube With 50mm Stem, Includes one S-5-400-7 NMR tube to be used with the Coaxial Insert.

View In Legacy Store

We cannot guarantee the fit of any NMR tube other than the one that is provided with the insert.

Item No.:

NI5CCI-B-QTZ

Tube:

5mm

Probe:

Bruker

STEM SPECIFICATION
O.D. (mm):

3

STEM SPECIFICATION
Length (mm):

50

STEM SPECIFICATION
Capacity (μl):

175

Sample Capacity:

285 μL

NI5CCI-V-QTZ Varian Coaxial Inserts for NMR Tubes, 4mm Quartz Tube With 60mm Stem, Includes one S-5-400-8 NMR tube to be used with the Coaxial Insert.

View In Legacy Store

We cannot guarantee the fit of any NMR tube other than the one that is provided with the insert.

Item No.:

NI5CCI-V-QTZ

Tube:

5mm

Probe:

Varian

STEM SPECIFICATION
O.D. (mm):

3

STEM SPECIFICATION
Length (mm):

60

STEM SPECIFICATION
Capacity (μl):

210

Sample Capacity:

340 μL
